Knitted Wire Mesh

Knitted Wire Mesh

Knitted wire mesh is a diverse material with virtually countless applications across most industry sectors,mesh can be grouped into five broad categories: fine, medium-fine, standard, coarse and super-coarse, but these divisions can cover a wide range of products. Using various filament diameters and mesh sizes, along with different crimping, calendaring, folding, layering and rolling processes, the product scope is almost unlimited.

Main products: knitted wire mesh, knitted wire filters, breathers, eliminators, gaskets, compressed knitted wire mesh and series knitted wire products.



Wire diameter

Hole


Fine mesh

0.10mm-0.18mm

2x3mm etc


Medium/Fine Mesh

0.15mm-0.2mm

3x4mm etc


Standard Mesh

0.2-0.35mm

3x4mm or 4x5mm etc


Coarse Mesh

0.2mm-0.35mm

5x6mm/5x7mm/5x8mm etc


Super/Coarse Mesh

0.3-0.5mm

5x6mm/5x8mm/7x8mm/6x8mm/5x10mm etc.

Product width

3mm -1220mm

Roll length

3mm-100000mm

Material

PP, PE, PTFE, PVDF, Galvanized wire, stainless steel wire, copper wire, copper tinned wire, Monel alloy wire, alloy wire, stainless steel + glass fiber mixed wire, etc.
